Powermat PMT 300 Wireless Power Solution
Powermat PMT 300 is a medium to high wireless power solution up to 300W and can be tailored to fit specific product requirements based on Powermat SmartInductive™ Technology. The Powermat solutions supply the power, magnetics, and interface to meet customer product requirements. Powermat solutions deliver pinnacle flexibility, safety, and cost-efficiency for a 100% wireless life.
Datasheet Download
PMT 300 Applications
- Industrial and commercial robotics
- High power domestic robotics
- Large drones
- High power Telecom edge technology (CPE)
- Handheld devices and power tools
- E-bikes
- E-carts
- Large batteries
PMT 300 Specifications
| Product | PMT 300 | ||
| Category | Performance | ||
| Description | High voltage, high current | ||
| Functionality | Rx/Tx/RxTx | ||
| Max power | 300W | ||
| Wireless power protocol | Custom | ||
| Output: | |||
| Load type | Fixed voltage /Battery (charging algorithm) | ||
| Max voltage | 50V | ||
| Max current | 10A | ||
| Input: | |||
| Input source | Fixed DC/Battery/PV (MPPT algorithm) | ||
| Max voltage | 50V | ||
| Max current | 10A | ||
| Host interfaces | IO/UART (RS232/LVTTL)/CAN | ||
| Data overpower | + | ||
| FOD | Q factor/Advanced | ||
| Coil size | Custom- up to 200mm | ||
| Coil to coil distance | 5mm-200mm (coil dependent) | ||
| Coils lateral misalignment | Up to 50mm (coil dependent) | ||
| PCB size | 55mm x 55mm |
